RSDK and RSDK Atlas
DeepUnity PACSonWEB supports RSDK speech recognition and RSDK Atlas Engine. These paid features can only be activated by your local DeepUnity PACSonWEB service partner.
|
Important |
|
|
To enable the RSDK Atlas engine, contact your local DeepUnity PACSonWEB service partner for assistance with activating an additional User Option and setting Rsdkatlas = true.
|
Once activated, the following buttons become accessible while editing a report:
Playback feature
The dictated text can be played back using specific buttons in the report editor or their corresponding shortcuts.
|
Button
|
Functionality
|
Action
|
Shortcut
|
|---|---|---|---|
 |
Play
|
Click
|
ALT+F1
|
 |
Stop
|
Click
|
ALT+F1
|
 |
• Return 1 word
• Rewind a ratio of 10 words / second
|
• Click
• Click and hold
|
ALT+F11
|
 |
• Skip 1 word
• Fast forward a ratio of 10 words / second
|
• Click
• Click and hold
|
ALT+F12
|
|
Tip |
|
|
If you are using a multimedia keyboard, you can also use the corresponding play buttons on your keyboard.
|
The play features can also be controlled using a foot pedal, by configuring the following key combinations:
|
Functionality
|
Shortcut
|
|---|---|
|
Play / Stop
|
ALT+F1
|
|
Start / stop fast forwarding
|
CTRL + ALT + F12
|
|
Start / stop rewinding
|
CTRL + ALT + F11
|
Synchronous playback
• Select a word or phrase and press play: The audio for the selected text will play and stop at the end.
• Place the cursor at a certain location in the text and press play: The audio will play from the cursor position until the end of the text.
• Click stop during playback: The audio will stop, and the cursor will be placed at the corresponding spot in the text.
Available voice commands
• microphone off
• (go to) beginning of report
• (go to) beginning of document
• (go to) end of report
• (go to) end of document
• (go to) beginning of line
• (go to) end of line
• select line
• select sentence
• select paragraph
• select all
• select everything
• cut text
• copy text
• paste text
• delete that
• scratch that
• make bold
• underline
• italicize
• start bullet list
• end bullet list
• all caps
• format title/format as title: This voice command will activate the Heading 1 formatting as configured in Preferences section Reporting.
For help on dictation, see section Dictation Help RSDK in the user manual or visit the help page of RSDK https://recognosco.com/help-support
.
.|
Caution |
|
|
The recognized text is not always 100% correct. It is the responsibility of the radiologist to verify the correctness of the report before validation.
|
